Meridian makes aluminum soffit in both the “Double Six” and the “Triple Four” profiles.
The D6 profile is run from a .019” coil. The T4 passes the same bending test with a slightly thinner gage thanks to the added “V” in the center of the panel. The .0175” T4 gauge accounts for the price savings of the T4.
Both products are 12’ long panels and packaged at 16 boards per box, yielding just under two sq. per box (192 linear feet x 1 foot wide).
Our 1/2” J-Channel fits the D6 and the 7/16” J for the T-4.
To enlarge the image, hover over and click the image.
